69.5″ Gelato Display Showcase (Black Exterior) with 13 Pans

• Black Exterior

• Internal LED on top

• Digital controller

• Dual LED temp. displays inside and at back

• Sliding doors at back

• Front curved glass

• 4 casters, 2 with brakes

• Ventilating cooling system

• Automatic defrost

Technical

ITEM: 47572

MODEL: FR-CN-0013W

ELECTRICAL: 110v – 120v / 60hz

CURRENT: 13.6A

POWER: 1500W

TEMPERATURE RANGE: -12 to -22°C / 10.4 to -7.6°F

MAX AMBIENT TEMP RATING: 23.9°C / 75°F

REFRIGERANT: R290 (160g)

COOLING SYSTEM: Ventilated

CLIMATE CLASS: 4

TEMPERATURE CONTROLLER: Digital Control

TEMPERATURE DISPLAY: LED Display

TYPE OF LIGHT: LED

DEFROST: Auto-defrost with the heating element

TRAY HEATER: No

DOOR TYPE: Sliding doors at the back

SELF-CLOSING DOOR: No

PAN QUANTITY: 13 x 5L (Ice Cream Pan) 1 Scoop Pan

ICE CREAM PAN DIMENSIONS: 14.2” x 6.5” x 4.5” / 360 x 165 x 115 mm

SCOOP PAN DIMENSIONS: 6.5” x 7.6” x 2.4” / 165 x 149 x 60 mm

ADJUSTABLE SHELF HEIGHT: No

UNIT DIMENSIONS: 69.5″ x 33″ x 51″ / 1764 x 850 x 1300 mm

PACKAGING DIMENSIONS: 72.5″ x 37.8″ x 57″ / 1842 x 960 x 1460 mm

UNIT WEIGHT: 434 lbs. / 197 kg.

PACKAGING WEIGHT: 582 lbs. / 264 kg.
