Table Model Meat Grinder with 1.5 HP Motor

FEATURES:

• Stainless steel filling tray

• Knives and plates made of carbon steel

• Overheating protection

• Rugged gearbox made of steel, with oil bath

• Use of durable materials results in a long-lasting machine

• Extremely energy and production efficient

• Quiet and generates less heat

Description

Robust and durable

This powerful table model meat grinder includes a large stainless steel filling tray, #22 knife and plate, removable head, feed screw and ring. It features an extraordinarily robust motor-gear unit, 1 set of single cutting systems and safety switch to ensure efficient operations and the best cutting results at any time.

Large filling tray with hand protection

• Completely made of stainless steel

High-quality knives & plates

• Knives and plates made of special carbon steel of the highest strength and durability.

• This material is characterized by significantly lower wear and tear, which prolongs the service life of the knives and plates and prevents contamination of the meat by abrasion of metal particles as with soft stainless steel alloys.

Extraordinarily robust motor-gear unit

• High performance and energy efficiency, quieter and less heat generation

• Overheating protection

• Rugged gearbox made of steel, with oil bath

• Automatic safety switch

Technical

Tray Capacity: 10.6 Qt. (10 L)

Diameter of Mincer Plate: 3.26 mm

Cutting System: Single Cut

Single Cutting System: (2) Plates, hole dia. 0.17” & 0.3” (4.5 & 7.8 mm) (1) Cutting knife

Operating Temperature: 40° – 100° F (5° – 40° C)

Operating Relative Humidity: 20 – 99%

Output Per Hour: 771 lb. (350 kg.)

Power: 1100 W / 1.5 hp

Electrical: 208V / 60Hz / 3Ph

Amps: 4.3 A

Noise Level at 1m: 60 dB(A)

Net Weight: 110 lb. (50 kg.)

Net Dimensions (WDH): 23.7” x 12.2” x 18.2” (600 x 310 x 460 mm)

Gross Dimensions (WDH): 28” x 14” x 20” (711 x 356 x 508 mm)
