24 QT Heavy-duty Spiral Dough Mixer, 2 speed – 208V, 1.5HP/1HP, 3Ph

Description

Your next commercial application for handling large batches with ease.

This dough mixer features robust, fixed stainless steel high-strength spirals and is capable of handling substantial flour and dough capacities. Whether you’re preparing pizza, cookies, or bread, you’ll see a significant boost in kitchen efficiency once this mixer becomes part of your setup.

FEATURES:

• Easy to use Control

• Grated Lid for Safety

• Made of stainless steel

• Fixed stainless steel high-strength spirals

• Safety device that stops the machine when the bowl cover is lifted

• Greatly reduce the usual mixing time of traditional machines

• Ideal for bakeries and pizza shops, these mixers perform well with both hard and soft dough

Technical

Bowl Capacity: 24 QT

Max Dry Flour Capacity: 24 lb. (11 kg.)

Max Dough Capacity: 40 lb. (17 kg.)

Bowl RPM: 1st Speed – 6 | 2nd Speed – 12

Spiral RPM: 1st Speed – 60| 2nd Speed – 120

Power: 1.5 / 1 hp | 1100 / 750 W

Amps: 3.8 | 2.6 A

Electrical: 208V / 60Hz / 3Ph

Bowl Dimensions (diaH): Ø 14.4” x 9.64” (366 x 245 mm)

Net Weight: 161 lb. (73 kg.)

Net Dimensions (WDH): 27” x 15.4” x 26.4” (686 x 391 x 671 mm)

Gross Weight: 175 lb. (79 kg.)

Gross Dimensions (WDH): 29” x 17” x 29” (737 x 432 x 737 mm)
