90QT Heavy-duty Spiral Dough Mixer, 2 speed – 208 V, 4.0/2.0 HP, 3 Ph

Description

Your next commercial application for handling large batches with ease.

This dough mixer features robust, fixed stainless steel high-strength spirals and is capable of handling substantial flour and dough capacities. Whether you’re preparing pizza, cookies, or bread, you’ll see a significant boost in kitchen efficiency once this mixer becomes part of your setup.

FEATURES:

• Easy to use Control

• Grated Lid for Safety

• Made of stainless steel

• Fixed stainless steel high-strength spirals

• Safety device that stops the machine when the bowl cover is lifted

• Greatly reduce the usual mixing time of traditional machines

• Ideal for bakeries and pizza shops, these mixers perform well with both hard and soft dough

Technical

Bowl Capacity: 90 QT

Max Dry Flour Capacity: 82 lb. (37 kg.)

Max Dough Capacity: 132 lb. (60 kg.)

Bowl RPM: 1st speed – 7 | 2nd speed – 14

Spiral RPM: 1st speed – 70 | 2nd speed – 140

Power: 4 / 2 hp | 3000 / 1500 W

Amps: 10 / 5.2 A

Electrical: 208V / 60Hz / 3Ph

Bowl Dimensions (diaH): Ø 21.7” x 14.2” (551 x 361 mm)

Net Weight: 407 lb. (184.6 kg.)

Net Dimensions: 39″ x 23″ x 42″ (991 x 584 x 1067mm)

Gross Weight: 534 lb. (242 kg.)

Gross Dimensions (WDH): 47” x 36” x 58” (1194 x 914 x 1473 mm)
