40QT Heavy-duty Spiral Dough Mixer, 1 speed – 220V, 1.5 HP, 1 Ph

Description

Your next commercial application for handling large batches with ease.

This dough mixer features robust, fixed stainless steel high-strength spirals and is capable of handling substantial flour and dough capacities. Whether you’re preparing pizza, cookies, or bread, you’ll see a significant boost in kitchen efficiency once this mixer becomes part of your setup.

FEATURES:

• Easy to use Control

• Grated Lid for Safety

• Made of stainless steel

• Fixed stainless steel high-strength spirals

• Safety device that stops the machine when the bowl cover is lifted

• Greatly reduce the usual mixing time of traditional machines

• Ideal for bakeries and pizza shops, these mixers perform well with both hard and soft dough

Technical

Bowl Capacity: 40 QT

Max Dry Flour Capacity: 40 lb. (18 kg.)

Max Dough Capacity: 66 lb. (30 kg.)

Bowl RPM: 7

Spiral RPM: 95

Power: 1.5 hp / 1100 W

Amps: 5 A

Electrical: 220V / 60Hz / 1Ph

Bowl Dimensions (diaH): Ø 14.7” x 11.6” (373 x 295 mm)

Net Weight: 246 lb. (111.6 kg.)

Net Dimensions: 30″ x 16.5″ x 36″ (762 x 419 x 914 mm)

Gross Weight: 265 lb. (120 kg.)

Gross Dimensions (WDH): 32” x 18” x 38” (813 x 457 x 965 mm)
