SPIKA NG285 - UNDER COUNTER ICE MAKER
![SPIKA NG285 - UNDER COUNTER ICE MAKER](https://i.machineryhost.com/460b491b917d4185ed1f5be97229721a/99389df9fb27a8e88dc6bf08adc4c466/large-f5ce5d_11bdcb16c6474df79a7d6e33234f5a51_mv2.jpg)
SPIKA NG285 - UNDER COUNTER ICE MAKER
C$3,850 (CAD)
orCall +1 604-831-4796
Description
OPERATING LIMITS: Tropicalized machines (Class T); Suitable for low temperature environments of 41° (5°C) Air and Water and high temperature environments of 109⁰F (43⁰C) (Air), 95°F (35°C) (Water) Water pressure: Min. 10 psi. (0.7 bar.)/ Max. 85 psi. (6 bar.).
MORE ENERGY EFFICIENT: SPIKA Series are Energy Star® qualified machines, reducing water and electricity consumption. WARRANTY: 36 months parts and labor + 24 additional months parts on compressor and evaporator. Valid in the U.S. and Canada. Contact for warranty in other countries.
Specifications
Condition | New |
Stock Number | ITV-SPIKA-NG285 |
New water distributor | Increases resistance against scale build up. Easily removable and cleanable. |
Inlet water connection through evaporator | Helps to harvest; precools water; assists energy recovery. |
Seal-less pump outside ice zone electromechanical controls | The machine works with electromechanical timer and thermostats. Simple, easy to comprehend and service. High reliability and low maintenance expense. |
Dual switch | External switch allows to turn the machine on/off easily. Removing the top cover, we have the ice/wash switch on one side of the electrical box. |
Strong inox frame. 304 stainless steel construction | Box-type frame with stainless steel supports, makes the machine stronger and allows servicing operation without disassembling the entire machine. |
Easy access for service and installation | Designed to have better access to all components making installation and servicing operations easier. One person can disassemble the entire machine with a basic screwdriver. |
Front ventilation | Condensing unit permits 100% front ventilation, air inflow and outflow through the front grill, thus permitting embedded installation. |
Insulated storage bin | Storage bin with polyurethane foam insulation gives higher rigidity with lower heat transmission. Isolated but not refrigerated bins. Tight closing of stainless steel door helps maintain ice storage longevity. |
Note | Install a pressure reducer if water inlet pressure is more than 85 psi. (6 bar.). |
Electrical specifications | 115V/60Hz./1 - Fuse Size 15 - Nema Plug Type 5-15P. Also available 208-230V/60Hz. - 220V/50Hz. (Special order only. Restrictions may apply. Contact dealer for details.) |
